Fibaro RGBW Controller 2 Z-Wave+ LED Controller
The Fibaro RGBW Controller 2 is a versatile Z-Wave Plus module designed to control RGB and RGBW LED strips, as well as other low-voltage lighting systems. Compact and powerful, it enables precise color management and energy monitoring for a fully customizable lighting environment.
Advanced Lighting Control
Using PWM signal output, this controller allows smooth adjustment of colors and brightness across LED, RGB, RGBW lighting, and compatible resistive loads such as halogen lamps. It supports both 12V and 24V DC power supplies, making it suitable for a wide range of installations.
Create Personalized Ambiances
Transform your interior atmosphere effortlessly by adjusting lighting to suit your mood or activity. Whether for relaxation, work, or entertainment, the controller lets you create dynamic lighting scenes directly from your smartphone or via voice commands.
Smart Automation and Sensor Integration
Equipped with four analog inputs (0–10V), the module can connect to sensors such as temperature, humidity, or light sensors. This allows intelligent automation based on environmental conditions, enhancing comfort and efficiency.
Energy Monitoring and Efficiency
The RGBW Controller 2 measures both real-time power consumption and total energy usage across all channels. This feature helps optimize energy use and reduce electricity costs.
Seamless Z-Wave Integration
Compatible with Z-Wave Plus technology, the controller integrates بسهولة into any Z-Wave network. It supports S2 security and can be updated wirelessly via compatible controllers such as Fibaro Home Center.
Key Features
- Z-Wave+ RGB / RGBW lighting controller
- Compatible with 12V and 24V DC systems
- Supports LED strips, RGBW lighting and resistive loads
- 4 analog inputs (0–10V) for sensors
- 4 independent outputs
- Power and energy consumption measurement
- Custom lighting scenes and automation
- Wireless firmware updates (OTA)
- Compact and easy to install
Technical Specifications
- Power supply: 12V DC / 24V DC
- Maximum output power: 12A total
- Load capacity: 144W (12V) / 288W (24V)
- Power consumption: <0.3 W
- Frequency: 868.42 MHz
- Range: up to 50 m outdoors / 30 m indoors
- Dimensions: 42 × 37 × 17 mm
- Operating temperature: 0°C to 40°C
