Heatit - Z-Wave+ multifunction smoke detector 230V

Heatit Z-Smoke Z-Wave Multifunction Smoke Detector (Mains Powered)

The Heatit Z-Smoke is a multifunction wireless smoke detector designed for smart home systems, offering enhanced protection against fire hazards. With its sleek and compact design, it integrates discreetly into any interior while delivering reliable safety features.

Advanced Fire Detection Technology

Using a high-performance photoelectric sensor combined with an advanced microprocessor, the device accurately detects smoke and heat from developing fires. It delivers a powerful 85 dB alarm to ensure immediate awareness in case of danger.

Multifunction Features for Smart Homes

Beyond smoke detection, the Heatit Z-Smoke includes a built-in PIR motion sensor and temperature sensor. These features allow you to create automation scenarios, such as activating lights at night or optimising heating based on occupancy.

Integrated Emergency Lighting

The built-in emergency light provides additional safety by offering visual alerts and improved visibility during alarms or power outages, enhancing protection in critical situations.

Reliable Power and Backup

Powered by mains electricity (230V AC), the detector also includes a rechargeable NiMH backup battery to ensure continued operation in case of power failure.

Seamless Z-Wave Integration

Compatible with Z-Wave Plus networks, the device can communicate with other connected equipment to trigger alarms, notifications, or automated safety responses. It supports secure communication protocols including S0 and S2.

User-Friendly and Secure Design

The detector features a mute button to silence unwanted alarms, a tamper switch for added protection, and firmware updates via OTA. Its design ensures both ease of use and long-term reliability.

Key Features

• Multifunction smoke detector with photoelectric sensor
• Mains powered with backup battery
• Integrated motion (PIR) and temperature sensors
• Built-in emergency lighting
• Z-Wave Plus connectivity
• 85 dB alarm output
• Low battery warning and tamper protection
• Mute button for alarm control
• OTA firmware updates
• Supports S0 and S2 security protocols

Technical Specifications

• Protocol: Z-Wave Plus (868.4 MHz)
• Chip: Z-Wave 500 series
• Power supply: 230V AC, 50 Hz with NiMH backup battery (200 mAh)
• Alarm level: 85 dB at 3 m
• Temperature sensitivity: ±1°C
• PIR detection range: up to 8 m (at 3 m height)
• Operating temperature: 0°C to 50°C
• Humidity: up to 85% RH
• IP rating: IP20
• Dimensions: 105 × 105 × 41 mm
• Certifications: Z-Wave Plus, CE, RoHS, EN-14604
