Shelly BLU Motion ZB - Zigbee and Bluetooth PIR motion sensor + light sensor

Shelly BLU Motion ZB – Zigbee and Bluetooth Motion Sensor with Light Sensor

The Shelly BLU Motion ZB is a compact battery-powered sensor that combines PIR motion detection and ambient light measurement. Designed for smart home installations without wiring or drilling, it enables automated lighting, presence notifications, and custom automation scenarios based on real room conditions.

With dual Zigbee 3.0 and Bluetooth 5 LE connectivity, it integrates easily into existing smart home systems. Adjustable motion sensitivity and configurable light thresholds allow precise customization for different environments.

Compatible with Shelly Smart Control, Home Assistant, and BTHome-compatible platforms, it installs easily using the included double-sided adhesive tape. Its CR2477 battery provides up to 5 years of battery life.

Main Features

• Dual Zigbee 3.0 and Bluetooth 5 LE connectivity.
• PIR motion detection with adjustable sensitivity.
• Built-in ambient light sensor.
• Customizable light thresholds for automations.
• Simultaneous Zigbee and Bluetooth operation.
• BTHome compatibility.
• Beacon mode with status updates every 30 seconds.
• Motion notifications and alerts.
• Custom scene activation through compatible Shelly devices.
• JavaScript scripting support (gateway required).
• Configurable LED indicator.
• Tool-free installation using the included double-sided adhesive tape.
• Secure communication with AES encryption (CCM mode).

Technical Specifications

• Product Name: Shelly BLU Motion ZB
• Model: SBMO-103Z
• Bluetooth ID: 0x0013
• Dimensions: 28 × 37 × 37 mm
• Weight: 28 g
• Material: Plastic
• Color: White
• Operating Temperature: -20°C to 40°C
• Operating Humidity: 30% to 70% RH
• Power Supply: 1 × 3V CR2477 battery (included)
• Battery Life: Up to 5 years
• Built-in PIR sensor
• Built-in light sensor
• Bluetooth Version: 5 LE
• Bluetooth RF Band: 2400 – 2483.5 MHz
• Maximum Bluetooth RF Power: < 8 dBm
• Bluetooth Range: Up to 10 m indoors and 30 m outdoors
• Zigbee Protocol: IEEE 802.15.4
• Zigbee RF Band: 2405 – 2480 MHz
• Maximum Zigbee RF Power: < 8 dBm
• Zigbee Range: Up to 10 m indoors and 30 m outdoors
• Processor: EFR32MG27
• Flash Memory: 768 kB
• Encryption: AES (CCM mode)
• Beacon Mode: Yes

Compatibility

• Shelly Smart Control
• Home Assistant
• BTHome-compatible platforms
• Shelly Plus Series
• Shelly Gen3 Series
• Shelly Gen4 Series
• Shelly Pro Series
• Zigbee 3.0 hubs

Package Contents

• Shelly BLU Motion ZB Sensor
• Double-sided adhesive tape
• CR2477 battery
