Heatit - Zigbee 250W rotary dimmer switch

Heatit Zig Dim – Zigbee Rotary Dimmer Switch

The Heatit Zig Dim is a high-quality Zigbee rotary dimmer designed for smooth and flicker-free dimming of various light sources, particularly LED lighting. Supporting 2-wire installations, it is compatible with a wide range of luminaires and fits standard European wall boxes. Thanks to System 55 frame compatibility and an external momentary switch option, it offers flexible integration and intuitive manual control. Ideal for smart home environments using Zigbee 3.0.

Features:

• Zigbee 3.0 rotary dimmer switch
• Compatible with 2-wire installations
• Supports LED loads from 5W to 250W
• Rotary and push-button dimming control
• External momentary switch input
• Trailing edge dimming technology
• Adjustable minimum brightness level
• Automatic calibration of maximum dimming level
• Protection features: overload, overvoltage, short-circuit, overtemperature
• Fits European wall boxes and System 55 frames
• Nemko and CE certified
• OTA (Over-the-Air) updates supported

Technical Specifications:

• Protocol: Zigbee 3.0
• Radio Range: up to 40 m (indoor)
• Voltage: 230 V AC, 50 Hz
• Load Capacity: 5W – 250W (LEDs and other compatible loads)
• Control Method: Rotary and push dimming, external switch input
• Installation: Fits European wall boxes
• Connection: Screw terminals, 0.2 to 2.5 mm² cables
• Max Tightening Torque: 2 N·m
• Ambient Temperature: 5°C to 40°C
• Humidity: 10% to 85% RH
• Protection Rating: IP21
• Certifications: CE, Nemko
