Nexelec - Intelligent smoke detector INSAFE+ Origin DAAF Zigbee + Temperature/Humidity

INSAFE+ Origin: Multifunction Indoor Air Quality Sensor

INSAFE+ Origin is a must-have solution for Smart Home and Smart Building environments, offering advanced monitoring and automation in a single connected device.

Designed to cover three essential functions, this intelligent detector enhances:

• Safety: Protects individuals and property from fire hazards
• Comfort: Evaluates and helps improve indoor air quality (IAQ)
• Energy Efficiency: Regulates temperature and humidity levels

Fully compatible with smart ecosystems, INSAFE+ Origin communicates with connected devices to streamline everyday tasks and enable custom automation scenarios for occupants.

IAQ: A Key Component for Smart Building Performance

Utilizing a cutting-edge multi-sensor design, INSAFE+ Origin can replace multiple standalone units, leading to substantial savings in terms of equipment costs, installation, and maintenance.

Its indoor air monitoring capabilities help property managers, developers, public housing authorities, and municipalities boost building energy efficiency while delivering personalized services such as elderly care, heating cost reduction, enhanced comfort, and fire safety.

Package Contents

• 1 INSAFE+ Origin unit
• 1 wall mounting bracket
• 2 nylon screws and plugs
• 1 user manual

Main Features

• Continuous indoor air quality monitoring
• Comfort and IAQ improvement tips for users
• Temperature and humidity tracking history
• Integrated smoke detection with alarm
• False alarm detection algorithm with suggestions
• Battery level warning and end-of-life alert
• Manual device test mode
• Automated self-test every 45 seconds
• Pause function for 10 minutes
• 8-hour mute for low battery alarm
• Persistent “keep-alive” monitoring signal
• Maintenance and alarm event history
• Real-time device status and remaining battery indicator

Technical Specifications

• Indoor Air Quality: IZIAIR index with 5 levels
• Temperature measurement accuracy: 0.2°C
• Humidity measurement accuracy: 1% RH
• Smoke Detection: Photoelectric sensor using Tyndall effect
• Sound level: >85 dB at 3 meters
• LED indicators: Red and orange flashing lights
• Built-in insect barrier to prevent false alerts
• Data transmission frequency: From every 3 minutes to 6 hours, and instantly upon alarm
• Connectivity: Zigbee radio protocol

Physical & Environmental Details

• Power: 2 integrated sealed lithium batteries
• Battery lifespan: Up to 10 years
• Dimensions: 105 mm x 105 mm x 30 mm
• Weight: 150 g including battery and bracket
• Environment: Indoor residential use
• Operating temperature: 4°C to 45°C
• Operating humidity: 15% RH to 95% RH
• Wall-mounted installation

Certifications & Warranty

• CE certified
• Compliant with EN 14604 standard
• Warranty: 2 years
